Chenab Engineering Works & Foundries (Pvt.) Ltd., Design & Development is the foundation upon which every product we manufacture is built. Established in 1950 and continuously advancing, our engineering capabilities allow us to take a customer requirement from initial concept all the way through to a precision-machined, finished component that conforms to the most demanding international standards.
Our Design & Development Process
Engineering Innovation from Concept to Casting
Defense Components Developed Through Our Capability
Our Design and Development function has directly enabled the indigenization and manufacture of a wide range of complex defense components for Heavy Industries Taxila (HIT) and the Pakistan Army:
| Platform / vehicle | Links per vehicle | Dimensions (L × W × H) mm | Track type / notes |
|---|---|---|---|
| T‑72, T‑62 RMSh | 194 | 711.0 × 175.5 × 232.5 | 194 links per vehicle, RMSh track |
| T‑55 RMSh | 200 | 580.0 × 184.7 × 185.0 | 200 links per vehicle |
| T‑Series (T‑85, T‑69, T‑59) link assembly | 198 | — | 198 links per vehicle; covers T‑85, T‑69, T‑59 variants |
| T‑80UD | 160 | 574.0 × 161.0 × 205.5 | 160 links / vehicle |
| MBT‑2000 Al‑Khalid | 162 | 600.0 × 172.5 × 208.0 | Al‑Khalid MBT |
| VT‑4 | 162 | 600.0 × 172.5 × 209.0 | VT‑4 main battle tank |
| Al‑Zarrar | 162 | 572.0 × 149.5 × 214.0 | Al‑Zarrar (modernized T‑59) |
| M‑113 APC | 127 | 381.0 × 192.5 × 160.2 | armoured personnel carrier |
| M‑60 MBT | 160 | 711.0 × 175.5 × 232.5 | same shoe as T‑72 family |
| M88 (T‑107) ARV | 170 | 711.0 × 176.5 × 210.5 | armoured recovery vehicle |
| M88 (T‑142) ARV | 170 | 711.0 × 175.5 × 232.5 | M88 variant with T‑142 shoe |
| M‑109 A2 (T136) SP | 158 | 380.6 × 152.5 × 165.2 | self‑propelled howitzer |
| M‑110 A2 (T136) SP | 151 | 457.0 × 205.0 × 170.2 | 203mm self‑propelled gun |
